19
LED Lightings IP20 Standard LED Lighting / Signal Towers Handles / Hinges / Knobs / Slide Rails /

Handles
P.1367

Hinges
P.1383

A (Light Emitting Part Length) Catches Magnetic

Cable Part Detail φ3.3 P.1405
P (Mounting Pitch) φ4 Locks
L (Total Length)

15.5 22 Minimum bending radius R24 P.1414
35 Not
Side View of Mounting Part 1500
Material: Main Body: Aluminum Alloy Knobs
Available Fixing Bracket: 304 P.1431
Front Cover: Polycarbonate
5
Cable: PVC
Washer: Silicon Rubber
E The dimension P (mounting pitch) is the distance from the waist-shaped hole to the waist Surface Treatment Main Body: Clear Anodized
and cannot be used for positioning. Please be careful. Front Cover: Milky White Cover
Light
Input Light Emitting Part Temperature
Input
Total Mounting Luminous
Color
Part Number 2Power 3Color Length Pitch Flux Voltage Current Length Range Temperature Distribution Rails Linear Slide
1Type (W) L P (lm) (V) (A) A (°C) (Kelvin K) Angle
P.1448
5 223 215 500 0.13A 190 LED Lighting
-10 P.1466
W
C-LEDZ 10 (White) 388 380 1000 DC24 0.25A 355 45 About 6000 About
〜
120°
15 554 545 1500 0.37A 521 Signal Towers
P.1475
＊It is recommended to use U-shaped hole to install this product. If you use a round hole, please pay attention to the screw size.
Ordering Please order after selecting part number and parameters according to the selection steps 1 to 3.
Example Part Number (1Type) - 2Power - 3Color
C-LEDZ - 5 - W
How to search Search on MISUMI official website Step 1 Search on MISUMI official website Step 2 Select MISUMI economy series brand
on website By By
Type C-LEDZ Keyword led light

MISUMI contact MISUMI WEB “Chat” Install MISUMI APP
