Economy series Product Overview Technical Calculation Economy series
Cable Carriers Cable Carriers
QWhat is the Cable Carrier?
Economy series Saving · It can prevent the cable and wire tubes connected to the moving parts of the equipment from twisting, stretching and entanglement due
vs Standard Type
to movement.
· I t is suitable for supporting and guiding multiple cables connected to the linear motion part.
up to
· MISUMI Cable Carrier can be ordered simply by specifying the applicable single type and no need to select the part numbers for the
Cable Carriers 69 % QCable Carrier Selection
link and mounting bracket, respectively.
Shipment after assembly Step 1. Tentatively select cable carrier type.

Assembled products shipped Step 2. Select cable carrier size.
in a short delivery time, If required sizes are not available, select a different
type of cable carrier.
eliminating troublesome link
3 · C- : Light & Low load Series MISUMI logo model engraved Step 3. Calculate free span length 3
connections.
Cable Carriers / Cables / Heat Shrink Tubes Fans / Network USB Adapter / Switching Hubs · E- : Medium Load Series Selection completed Fans / Network USB Adapter / Switching Hubs Cable Carriers / Cables / Heat Shrink Tubes
Step 4. Calculate the required number of links
· Low dust & Low Noise Series

Step 1. Tentatively select cable carrier type.
Please tentatively select types referring to the following features, open-close methods and sizes.
Type Features Flap Open-Close System
Cable Carriers Slit Type Cables/hoses can be easily inserted in from both external and Insert the cable into the opening. Carriers Cable
C-MSU
Low noise featuring internal noise reduction structure
C-MSD internal circumference sides.
P.445 P.445
Machinery Cables Flap Closed Type Space-saving design enables protection and guide even for only Flaps do not open. Cables Machinery
one cable/hose.
C-MHF
Closed type, stronger resistance to twisting
P.455 Flaps open from either right or left. P.455
Cables for Signals Signals Cables for

Open along the inner or outer side of the bending radius
C-MPU
P.461 Flap Open-Close Type The cover can be opened and closed on the left and right. P.461
Low noise featuring internal noise reduction structure
C-MPD
Heat Shrink Tubes Tubes Heat Shrink

P.468 P.468
Step 2. Select cable carrier size. <Selection Examples>
Fans Select suitable Cable Carrier size for housing cables/hoses. One φ20mm cable needs to be stored. Fans
20/0.8=25 or more interior height is required
for the condition
that the cable O.D. must be within 80% of
P.480 <Size Selection Tips> interior height. P.480
Network Communication 100% 80% d 1Height Communication Network
O.D. of the cable / hose must be 80% or less than the interior height of the cable carrier.
2Occupied Space
Cable / hose must be within 60% of Cable Carrier Interior Content = Interior Height × Interior Width. (In addition,
for MPSPS, up to 70% of the cable carrier interior can be taken up.)
P.484 Above 10% of d Above 10% of d 3Bending Radius P.484
When housing different types of cables/hoses together, please select the cable carrier bending radius to meet
the maximum bending radius.
Switching Hubs * For sectional dimensions and bending 4Distance Between the Running Cable/Hose and Interior Wall Hubs Switching
The distance between the running cable/hose and Cable Carrier interior wall must be at least 10% of the
radius by type and size, please refer to
running cable / hose O.D.
5 Cable / Hose Mutual Distances
product pages.
The distance between adjacent cables/hoses must be at least 10% of the biggest cable O.D..
P.489 P.489
