Max.
Part Number Mounting Energy Max. Max. Length (L) B
4
3 Stopper Screw Stroke Absorbed (E’) Equivalent Collision T t d (Both
Mass
Cap Nut Nominal (S) Per Per (me’) Velocity L1 L2 d1 Surfaces
2
Cap
Cap not
1Type NO. (M) Cycle Minute (kg) (M/S) provided provided Width)
(J)
(J)
14
1210 M12×1.0 10 12 360 35 3 89.5 81 61 10 4 8.5 10.5 3 14
1412 M14×1.5 12 21 410 90 2.5 107.2 95.2 70.2 13 5 12 12 4 19 Shock Absorbers / O-Rings Air Cylinders / Valves / Regulators /
1415 M14×1.5 15 22 440 120 3.2 129 117 89 13 5 12 12 4 19

1425 M14×1.5 25 28 460 140 3.2 154 142 104 13 5 12 12 4 19 Accessories Cylinders and

1612 M16×1.5 12 22 420 150 3.2 107.2 95.2 70.2 13 5 12 14 4 19 P.951

2016 M20×1.5 16 25 530 210 3 148.8 133 104 13 8 15.8 18 6 26 Absorber Shock

P.991
2020 M20×1.5 20 34 580 298 3.6 152.8 137 100 17 8 15.8 18 6 26
- SC
(Provided) (Provided) Bearings Rod End
C-AD 2025 N - M20×1.5 25 39 650 312 3.6 157.8 142 100 17 8 15.8 18 6 26
(Not (Not P.999
Provided) Provided)
2525 M25×1.5 25 85 1100 450 3.5 162 143.5 106 12.5 10 18.5 22 8 32 Floating Joint

2540 M25×1.5 40 100 1300 780 3.5 221.5 - 132 12.5 10 37 22 8 32
P.1004

2550 M25×1.5 50 98 1630 720 4.2 246.5 - 100 78 10 18.5 22 8 32 Silencer

2580 M25×1.5 80 150 2100 800 4.2 343 - 100 144.5 10 18.5 22 8 32 P.1006

2725 M27×1.5 25 90 1200 480 3.5 162 143.5 100 18.5 10 18.5 22 8 32 and Accessories Control Valves

P.1007
3625 M36×1.5 25 150 1500 1400 3.2 183 - 101 22 15 25 35 10 46

3650 M36×1.5 50 300 1800 1450 3.5 246 - 149 22 15 25 35.5 10 46 Handling Air Source
P.1015
EFor larger sizes, see the Economy series Shock Absorbers, Heavy Load Absorption Type catalog page.
EPlease visit MISUMI website for details of the models available for sale.
Please order after selecting part number and parameters according to the selection steps 1 to 4.
Ordering O-Rings
Example Part Number (1Type · 2No.) - 3Cap Provided / Not provided - 4Stopper Nut provided / Not provided
Example1C-AD1412
2C-AD1412 - N - SC P.1027
*1~3: Body of Shock Absorber
*4 : Optional Spare Part of Shock Absorber
