40 ALUMINUM FRAME
Slot Width 10mm: Series 40 for larger clean
Series booths, equipment bases and structural
materials (40, 80mm square)
When ordering, select Part Number and Values from Selection Steps 1~3.
Aluminum Frames 12Part Number - - 2000 Frames Aluminum
3L
NEFST8-4040

P.1183 Flat 40 6.7 2 4-R3 With Rotation Stopper P.1183
20
Brackets / Corners / Sheet Metals / Connectors 5.5 7 10 ⒷFrame Sheet Metals / Connectors Brackets / Corners /

P.1215 40 φ10.5 P.1215
6.7
Nuts / Bolts Material Length Weight Section Area Cross Sectional Moment of Inertia Explanation Nuts / Bolts
NEFST8-4040
2
2
Clear Anodize
Insert a joint guide in frame with M type hole.
upward.
4
4
P.1243 A6063S-T5 50~4000mm 1.51kg/m 558mm 2 ℓ x 9.92×10 mm 4 ℓ y 9.92×10 mm 4 For standard type, adjust the through hole to be P.1243
Decorative Accessories Curved R32 φ 8.8 20 Front View / Side View Accessories Decorative
Step 1
P.1258 2 20 40 P.1258
Panel Fasteners / Panels / Door Sliding Slot Accessories 2-R1 20 40 20 R3 Door Sliding Slot Accessories Panel Fasteners / Panels /

Clear Anodize
P.1262 NFSR8-4040 P.1262
17 Material Length Weight Section Area Cross Sectional Moment of Inertia Standard Type 17
A6063S-T5 50~4000mm 1.53kg/m 564mm 2 ℓ x 7.79×10 mm 4 ℓ y 7.79×10 mm 4
4
4
Aluminum Frames / Related Accessories Economy Type 20 2.7 1.9 6.8 6 40 7 5.5 4-R3 Related Accessories Aluminum Frames /

10
2- φ 10.5
40 2.5 20 80

With Rotation Stopper
NEFS8-4080 NEFSB8-4080 20
Clear Anodize Clear Anodize
Material Length Weight Section Area Cross Sectional Moment of Inertia
4
4
A6063S-T5 50~4000mm 2.79kg/m 1034mm 2 ℓ x 19.9×10 mm 4 ℓ y 72.6×10 mm 4
Light Weight Economy Type 40
7 5.5 4-R3

20
10 20 Explanation
2- φ 10.5 Move frame close to frame while putting the
40 1.5 80 center post through the through hole of joint guide.

NFSL8-4080 20
Clear Anodize
Material Length Weight Section Area Cross Sectional Moment of Inertia
4
4
A6063S-T5 50~4000mm 2.12kg/m 785mm 2 ℓ x 13.4×10 mm 4 ℓ y 52.9×10 mm 4
