Economy series Aluminum Extrusions Frame Assembly Aluminum Extrusions Load Capacity Guideline Economy series
Aluminum Frames Aluminum Frames

Prior to Beginning 1 Assembly of Single Joint Connected Type. 2 Mount the posts.
Bottom Frame Assy.
(1) Begin assembling with the bottom extrusion. Connect the corners with Single Joints.
1. Provide a large and flat work space for the (2) Center joist is connected with Pre Assy. Ins. Double
assembly. Joints.
(3) Insert the nuts prior to assembly.
2. Sort the extrusions into parts and sizes. 1Tighten temporarily with the
3. Count and confirm the qty. of the nuts to be pre-assembly insertion double joint.
pre-inserted. Tighten temporarily with the
pre-assembly insertion double joint.
* Insert any Pre Assy. Nuts needed at this point if
mounting a top plate and/or covers. 2 3Insert 2 pre-assembly fitting
nuts at the top of the extrusion.
This assy. example also shows installation of
Plate Type Adjusters and Casters.
2
3
2Insert 4 pre-assembly
nuts in the bottom of the frame to
attach Casters with Mounting Plates. 2
Single Joint Wrench Hole
* Do not forget to insert the nuts. Assembly Method
Pass the single joint
through and position it.
3 Mount the middle posts. 4 Top Frame Assy. (1) 5 Top Frame Assy. (2)
Connect the middle extrusions with Pre Assy. Ins. Pre-install Single Joints on the ends of four posts.
Double Joints.

Pass the single joint through and position it.
( Backlash should be kept. )
Insert pre-assembly insertion nuts Two Pre-Assembly Insertion
for pre-assembly double joints. Nuts for a Pre-Assembly
Insertion Double Joint

Pre-Assembly Insertion
Double Joints
Insert the pre-assembly
insertion nuts. Slide and insert.

6 Adjuster and Caster Mounting 7 Final Tightening 8 Surface Cleaning
Attach extrusion end caps.

Invert the unit and mount the adjusters and casters. Fully tighten while adjusting the extrusion positions. Wipe clean the surfaces with alcohol, etc. after the assy. work.
(Adjusters and Casters are sold separately.)
