Part Number 5Shaft Bore Specs. P Pulley Timing
1Type 2Number of Teeth 3Belt Type 4 Pulley Shape Hole Dia. d P.D. O.D. D F E
H5M090 8
14 22.28 21.14 14 26 16
H5M150 8 P.529
H5M090 8
15 23.87 22.73 15 28 18
H5M150 8
H5M090 8·10
C-HTPA 16 B 25.46 24.32 17 32 20 Idlers
H5M150 8·10
H5M090 8·10
18 28.65 27.51 19 33 22
H5M150 8·10
H5M090 10 P.551
20 31.83 30.69 19 36 24
H5M150 10
Part Number 4 Pulley Shape 5Shaft Bore Specs. N P.D. O.D. D F E
1Type 2Number of Teeth 3Belt Type Hole Dia. d Timing Belts
H5M090 8
16 25.46 24.32 17 32 20
H5M150 8
H5M090 8·10 P.577
18 28.65 27.51 19 33 22
H5M150 8·10
H5M090 10
20 31.83 30.69 19 36 24
H5M150 10 Belts Closed End
H5M090 10·12
22 35.01 33.87 24 40 27
C-HTPA H5M150 B 10·12
H5M090 10·12 P.605
24 38.2 37.06 27 45 30
H5M150 10·12
H5M090 10·12·14
25 39.79 38.65 27 45 30
10·12·14
28 H5M150 10·12·14 44.56 43.42 32 48 35 Belts Open End
30 10·12·14 47.75 46.61 33 52 36
32 10·12·14·20 50.93 49.79 37 55 40
EDetailed specifications are available on the official website P.611
Ordering Please order after selecting part number and parameters according to the selection steps 1 to 5.
Example Part Number (1Type · 2Number of Teeth · 3Belt Type) - 4Pulley Shape - 5Shaft Bore Specs. / Hole Dia. (P/N) Open End Belts Clamp Plates for
C-HTPA20H5M090 - A - N12
Example · Specifications P.615
Purpose · Action 5
· A mechanism that shuttles a 2-stage positioning stage for
transferring workpieces.
· Rotary motion is converted to linear motion by a motor and
timing belt.
· 2 positioning stages are driven by a single driving Idlers / Timing Belts Timing Pulleys /
Material Pulley: Aluminum Alloy mechanism.
Flange: Aluminum Alloy
Surface Treatment: Clear Anodize · Environment · Operability
· An automatic mechanism that drives 2 positioning stages
by a single driving mechanism.
· Structure and design points
· 2 belt travel directions can be obtained after rotating the
motor, both can fix the positioning stage.
· Image recognition is performed, and workpieces are
transferred by multi-axis robots, and rough stopping
accuracy is sufficient.
· The plate is welded under the groove to increase the
plate thickness that is reduced due to the fixed surface
processing.
· Micro optical sensors for origin determination and micro
optical sensors (to prevent over-travel) have been used as
a measure to prevent failure.
· Crossing of upper and lower positioning stages may result
in injury. Therefore, this unit is provided with a cover
outside the surrounding components or devices to ensure
that it can be used in places inaccessible to hands.
How to search Search on MISUMI official website Step 1 Search on MISUMI official website Step 2 Select MISUMI economy series brand
on website By By
Type C-HTPA Keyword pulley htd
