AK AK
M M
5
Part Number 4 Shaft Bore Specs. Pulley Timing
2 Pulley P P.D. O.D. D F E
1Type Number 3Belt Type Shape Hole Dia. d P.529
of Teeth (1mm increments)
18 12~26 45.84 44.47 32 51 36
19 12~28 48.38 47.01 35 55 39 Idlers
20 12~30 50.93 49.56 36 57 41
21 H8M200 12~32 53.47 52.10 40 60 46
A:22
＊
22 ＊ W:27 12~34 56.02 54.65 41 60 46 P.551
24 12~40 61.12 59.75 46 67 50

25 H8M250 12~40 63.66 62.29 48 69 54 Timing Belts
26 ＊ A:28 14~45 66.21 64.84 51 75 55
28 ＊ W:33 14~48 71.30 69.93 55 78 58 P.577
C-HTPA 30 A 14~50 76.39 75.02 60 86 66
B
32 H8M300 14~55 81.49 80.12 63 86 66
34 ＊ A:33 16~60 86.58 85.21 70 94 74 Belts Closed End
36 ＊ W:38 16~65 91.67 90.30 75 99 78

38 16~65 96.77 95.40 80 105 84 P.605
40 H8M400 20~65 101.86 100.49 85 112 90
A:44
44 ＊ ＊ W:49 20~65 112.05 110.68 90 119 100
48 20~65 122.23 120.86 100 131 111 Belts Open End
50 20~65 127.32 125.95 100 135 115
60 20~65 152.79 151.42 100 160 140 P.611
5
Part Number 4 Shaft Bore Specs.
2 Pulley N P.D. O.D. D F E Open End Belts Clamp Plates for
1Type Number 3Belt Type Shape Hole Dia. d
of Teeth (1mm increments)
18 12~26 45.84 44.47 32 51 36 P.615
19 12~28 48.38 47.01 35 55 39 5
20 H8M200 12~30 50.93 49.56 36 57 41
21 ＊ A:22 12~32 53.47 52.10 40 60 46
22 ＊ W:27 12~34 56.02 54.65 41 60 46
24 12~40 61.12 59.75 46 67 50 Idlers / Timing Belts Timing Pulleys /
25 H8M250 12~40 63.66 62.29 48 69 54
26 ＊ A:28 14~45 66.21 64.84 51 75 55
28 ＊ W:33 14~48 71.30 69.93 55 78 58
C-HTPA 30 A 14~50 76.39 75.02 60 86 66
B
32 H8M300 14~50 81.49 80.12 63 86 66
34 ＊ A:33 16~50 86.58 85.21 70 94 74
36 ＊ W:38 16~50 91.67 90.30 75 99 78
38 16~50 96.77 95.40 80 105 84
40 H8M400 20~50 101.86 100.49 85 112 90
44 ＊ A:44 20~50 112.05 110.68 90 119 100
48 ＊ W:49 20~50 122.23 120.86 100 131 111
50 20~50 127.32 125.95 100 135 115
60 20~50 152.79 151.42 100 160 140
EDetailed specifications are available on the official website
Please order after selecting part number and parameters according to the selection steps 1 to 5.
Ordering
Example Part Number (1Type · 2Number of Teeth / 3Belt Type) - 4Pulley Shape - 5Shaft Bore Specs. / Hole Dia. (H/P/N)
C-HTPA22H8M250 - A - N14
How to search Search on MISUMI official website Step 1 Search on MISUMI official website Step 2 Select MISUMI economy series brand
on website By By
Type C-HTPA Keyword pulley htd

MISUMI contact MISUMI WEB “Chat” Install MISUMI APP
MISUMI WEB
Tel: 038-959200 or 1382
Email: cs@misumi.co.th 544

110310874739
