                 QDimension Specification Table (Both Sides Bearing)                                       Pulley  Timing
                      Part Number                                                    Bearing Nominal Model
                                                                                        and Dimension
                                                4 Shaft
                                     3Belt Type  Bore Dia. d  P.D. O.D.  F  E  A  W  Dh                   P.529
                   1Type    2Number                                                     No.     D   B
                            of Teeth
                                       XL025                             7.5 12.5                          Idlers

                                       XL031                              9   14                          P.551
                              16                  5     25.87 25.36 32  20        11  695ZZ×2  13   4
                                       XL037                              11  16                           Timing Belts

                                       XL050                              14  19                          P.577
                  C-AATFW
                                       XL037                              11  16                           Belts
                              18                  6     29.11 28.6  36  24        13  696ZZ×2  15   5       Closed End
                                       XL050                              14  19
                                                                                                          P.605
                                       XL037                              11  16
                              20                  8     32.34 31.83 40  27       16.5  698ZZ×2  19  6      Belts  Open End
                                       XL050                              14  19
                                                                                                          P.611
                 E Please visit MISUMI website for details of the models available for sale.
                          Please order after selecting part number and parameters according to the selection steps 1 to 4.
                 Ordering
                  Example  Part Number (1Type · 2Number of Teeth · 3Belt Type)  -  4Shaft Bore Dia. d      Open End Belts  Clamp Plates for
                                        C-AATF18XL025
                                                                                                          P.615
                      Example                                             · Specifications                 5
                                                                            Purpose · Action
                                                                          ·  A mechanism that shuttles a 2-stage positioning
                                                                           stage for transferring workpieces.
                                                                          ·  Rotary motion is converted to linear motion by a
                                                                           motor and timing belt.          Idlers / Timing Belts  Timing Pulleys /
                                                                          ·  2 positioning stages are driven by a single driving
                                                                           mechanism.
                                                                          · Environment·Operability
                                                                          ·  An automatic mechanism that drives 2 positioning
                                                                           stages by a single driving mechanism.
                                                                          · Structure and design points
                                                                          ·  2 belt travel directions can be obtained after
                                                                           rotating the motor, both can fix the positioning
                                                                           stage.
                                                                          ·  Image recognition is performed, and workpieces
                                                                           are transferred by multi-axis robots, and rough
                                                                           stopping accuracy is sufficient.
                                                                          ·  The plate is welded under the groove to increase
                                                                           the plate thickness that is reduced due to the
                                                                           fixed surface processing.
                                                                          ·  Micro optical sensors for origin determination
                                                                           and micro optical sensors (to prevent over-travel)
                                                                           have been used as a measure to prevent failure.
                                                                          ·  Crossing of upper and lower positioning stages
                                                                           may result in injury. Therefore, this unit is
                                                                           provided with a cover outside the surrounding
                                                                           components or devices to ensure that it can be
                                                                           used in places inaccessible to hands.
