Proximity Sensors Flat Body
Representative model: C-Q10-N12
Shipping
354 THB 1 day
from
Volume Discount
Quantity 1~3 4~5 6~ Sensor Proximity
Discount Unit Price 15% 30%
E Shipping days may differ by Quantity. P.891
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Detection Distance 3mm Detection Distance 5mm
C-Q10-N11 (Normally Open) C-Q18-N01 (Normally Open) Microsensors Photo
C-Q10-N12 (Normally Closed) C-Q18-N02 (Normally Closed)
10 18 10 Input/Output Circuit Diagram
6 Sensing P.901
Sensing Surface Cable Color
Surface 8.5 D (Brown)+V
8 27 LED 22 26 Load Sensors Zone
5 30 (Black) Output +
9.1 φ 8 90° 5 Main Circuit Tr
φ 3.1 ZD { 100mA MAX. - P.913
LED (Blue) 0V 200mA MAX.
3.4 6.5
12.2 Internal Circuit External Connection Example Filters
φ 3.8-2M ZD: Surge Absorbing Zener Diodes
Tr: NPN Output Transistor P.918
D: Diode for Power Supply Reverse
Connection Protection
φ 2.8-2M Strips Power
Action Detection Operating Protection Operating Short Overload Detection Wire P.921
Circuit
Surface
Part Number Output Pattern Mode Distance Voltage Structure Temperature protection Current Material Length
L1
C-Q10-N11 NO Probes Contact
3mm 120mA P.924
12
C-Q10-N12 DC NC
Top
3-Wire Detection 10 IP67 -25°C YES ABS 2m
~
~
Type Type 30VDC +70°C
C-Q18-N01 (NPN) NO Power Strips / Contact Probes Sensors / Filters /
5mm 220mA
C-Q18-N02 NC
Ordering
Example Part Number
C-Q10-N12
How to search Search on MISUMI official website Step 1 Search on MISUMI official website Step 2 Select MISUMI economy series brand
on website By By
Type C-Q10-N11 Keyword proximity sensor
