Timing Pulley Driving Conveying Mechanism Reference price
Application Industries: Automotive part Electronic & Electrical Home appliance

This figure is a mechanism that uses a timing pulley to drive a timing belt to rotate and
move the product for conveying.
The timing pulley has compact structure, high transmission efficiency, smooth
transmission, low noise, cushioning and shock absorption, and can allow larger center
distance transmission.

01 Linear Guide ×1 P.313 02 Sensor ×3 P.904
01 Linear Guide ×1 02 Sensor ×3 03 Timing Pulley T5×1
Nominal model 15 Shape T Shape
Width 590mm Output PNP Type (Normally Open)
E-GMLG15-590 C-MSX672N

2,094 175

THB/pcs THB/pcs
Quantity Unit price Total price Quantity Unit price Total price
1 2,094 2,094 1 175 175
4 1,675 6,700 10 148 1,480

03 Timing Pulley T5×1 P.549 04 Clamp plate for open end belt ×1 P.616

Pulley Shape A Belt, Type T5
Belt Nominal Width 100 (10mm) Belt Width 10mm
Number of Teeth 22 C-TBCR-T5100
Round Hole (Shaft Hole Dia.
8mm) + Threaded Hole
C-TTPA22T5100-A-P8
222 94

THB/pcs THB/pcs
Quantity Unit price Total price Quantity Unit price Total price
1 222 222 1 94 94
10 189 1,890 30 80 2,400

05 Timing belt T5×1 P.601 06 Idler T5×1 P.571

Belt Nominal Width 100 (10mm) Both Sides Bearing
Belt Circumference Length 1100mm Belt Nominal Width 100 (10mm)
C-TTBN1100T5-100 Number of Teeth 20
Shaft Dia. 8mm
C-AHTFW20-T5100-8
191 397
06 Idler T5×1 05 Timing belt T5×1 04 Clamp plate for open end belt ×1
THB/pcs THB/pcs
Quantity Unit price Total price Quantity Unit price Total price
1 191 191 1 397 397
10 162 1,620 4 338 1,352

* All products prices are without tax. For prices reference, please visit MISUMI official website.
