Economy series Product Overview Area Sensors Thin Type
Area Sensors
New Representative model: E-ARST10-4-N
Products
Shipping
2,147 THB 1 day
from

Volume Discount
Quantity 1~3 4~5 6~ Sensor Proximity
Discount Unit Price 15% 30%
E Shipping days may differ by Quantity. P.891
E Quantity of volume discount above is for representative Part No. It may differ by the Part.

B1 Microsensors Photo

28 P.901
B1: Upper blind spot
2D B2: Lower blind spot Sensors Zone
D: Optical axis pitch
13.51 H: Grating protection height
L H L: Total grating height
P.913

B1 = 1/2 of optical axis pitch + 13mm Filters
B2 = 1/2 of optical axis pitch + 13mm
L = Number of optical axes × Optical axis pitch + 26mm
H = (Number of optical axes - 1) × Optical axis pitch P.918
B2

Part Number 3Number of Optical Protection Height H Total Height L Strips Power
(mm)
(mm)
1Type 2Optical Axis Pitch D Axes Multiple of 4Output Type H = (3 - 1) × 2 L = 3 + 26
Specified Unit 2
E-ARST 10 4~28 N (NPN Output) 30~270 66~306 P.921
20 P (PNP Output) 60~540 106~586
Types Thin Type QWiring Diagram +24V
Detection Distance 0~3m GND Probes Contact
Response Time ≤5ms Emitter (Brown) power supply positive pole +
(Blue) power supply negative pole -
★ Generic products on the market are only applicable to working Power voltage DC24V±10% (Black) CP sync line P.924
conditions of equal distances and constant speeds. Output NPN Output Type / 12
PNP Output Type
Circuit Protection Reverse Connection Protection / (Black) CP sync line
Output Short Circuit Protection
Resistant to Light Receiver (Brown) power supply positive pole +
Interference 10000Lux (Blue) power supply negative pole -
Material Aluminum Alloy (White) NPN / PNP signal line Power Strips / Contact Probes Sensors / Filters /
Cable With 0.2mm PVC Length 2.5m
2
Please order after selecting part number and parameters according to the selection steps 1 to 4.
Ordering
Example Part Number (1Type · 2D) - 3Number of Optical Axes - 4Output Type
E-ARST10 - 4 - N
Example

For finger detection Minimum For palm detection Minimum
Detectable Object φ15mm Detectable Object φ25mm
(optical axis pitch 10mm) (optical axis pitch 20mm)

10mm 20mm

How to search Search on MISUMI official website Step 1 Search on MISUMI official website Step 2 Select MISUMI economy series brand
on website By By
Type E-ARST Keyword area sensor
