Title
Pict
Title
Pict
KW
KW
Name
Date
Date
Name
AK AK
M M
Part Number 3Nominal Number Belt Circumference Part Number 3Nominal Number Belt Circumference Pulley Timing
1Type 2Belt Number Width of Teeth Length (mm) 1Type 2Belt Number Width of Teeth Length (mm)
1016H8M 127 1016 1768H8M 221 1768
1024H8M 128 1024 1776H8M 222 1776
1032H8M 129 1032 1784H8M 223 1784 P.529
1040H8M 130 1040 1792H8M 224 1792
1048H8M 131 1048 1800H8M 225 1800
1056H8M 132 1056 1824H8M 228 1824
1064H8M 133 1064 1840H8M 230 1840 Idlers
1072H8M 134 1072 1848H8M 231 1848
1080H8M 135 1080 1856H8M 232 1856
1088H8M 136 1088 1872H8M 234 1872
1096H8M 137 1096 1880H8M 235 1880 P.551
1104H8M 138 1104 1888H8M 236 1888
1112H8M 139 1112 1896H8M 237 1896
1120H8M 140 1120 1904H8M 238 1904
1128H8M 141 1128 1912H8M 239 1912
1136H8M 142 1136 1920H8M 240 1920 Timing Belts
1144H8M 143 1144 1936H8M 242 1936
1152H8M 144 1152 1944H8M 243 1944
1160H8M 145 1160 1952H8M 244 1952
1168H8M 146 1168 1960H8M 245 1960 P.577
1176H8M 147 1176 2000H8M 250 2000
1184H8M 148 1184 2008H8M 251 2008
1192H8M 149 1192 2016H8M 252 2016
1200H8M 150 1200 2032H8M 254 2032 Belts Closed End
1208H8M 151 1208 2048H8M 256 2048
1216H8M 152 1216 2056H8M 257 2056
1224H8M 153 1224 2080H8M 260 2080
1232H8M 154 1232 2096H8M 262 2096 P.605
1240H8M 155 1240 2104H8M 263 2104
1248H8M 156 1248 2120H8M 265 2120
1256H8M 157 1256 2160H8M 270 2160
1264H8M 158 1264 2176H8M 272 2176 Belts Open End
1272H8M 159 1272 2184H8M 200 273 2184
1280H8M 200 160 1280 2200H8M (20mm) 275 2200
1288H8M (20mm) 161 1288 2208H8M 250 276 2208
250
1296H8M (25mm) 162 1296 2224H8M (25mm) 278 2224 P.611
300
1304H8M 300 163 1304 2240H8M (30mm) 280 2240
C-HTBN 1312H8M (30mm) 164 1312 C-HTBN 2248H8M (40mm) 281 2248
400
1320H8M
400
2256H8M
1320
165
282
2256
1328H8M (40mm) 166 1328 2272H8M 500 284 2272
500
1336H8M (50mm) 167 1336 2304H8M (50mm) 288 2304 Open End Belts Clamp Plates for
1344H8M 850 168 1344 2320H8M 850 290 2320
1360H8M (85mm) 170 1360 2352H8M (85mm) 294 2352
1368H8M 171 1368 2392H8M 299 2392 P.615
1384H8M 173 1384 2400H8M 300 2400
1392H8M 174 1392 2488H8M 311 2488 5
1400H8M 175 1400 2504H8M 313 2504
1408H8M 176 1408 2536H8M 317 2536
1416H8M 177 1416 2560H8M 320 2560
1424H8M 178 1424 2600H8M 325 2600
1432H8M 179 1432 2656H8M 332 2656
1440H8M 180 1440 2688H8M 336 2688
1448H8M 181 1448 2736H8M 342 2736 Idlers / Timing Belts Timing Pulleys /
1456H8M 182 1456 2800H8M 350 2800
1464H8M 183 1464 2840H8M 355 2840
1480H8M 185 1480 2848H8M 356 2848
1512H8M 189 1512 3048H8M 381 3048
1520H8M 190 1520 3072H8M 384 3072
1528H8M 191 1528 3120H8M 390 3120
1536H8M 192 1536 3168H8M 396 3168
1552H8M 194 1552 3200H8M 400 3200
1560H8M 195 1560 3264H8M 408 3264
1576H8M 197 1576 3280H8M 410 3280
1584H8M 198 1584 3360H8M 420 3360
1600H8M 200 1600 3400H8M 425 3400
1608H8M 201 1608 3408H8M 426 3408
1624H8M 203 1624 3424H8M 428 3424
1640H8M 205 1640 3600H8M 450 3600
1648H8M 206 1648 3824H8M 478 3824
1656H8M 207 1656 4000H8M 500 4000
1680H8M 210 1680 4224H8M 528 4224
1696H8M 212 1696 4400H8M 550 4400
1704H8M 213 1704 4520H8M 565 4520
1720H8M 215 1720 4656H8M 582 4656
1728H8M 216 1728 5120H8M 640 5120
1760H8M 220 1760 EPlease refer to the official website for more specifications
Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering
Example Part Number (1Type · 2Belt Number) - 3Nominal Width
C-HTBN368H8M - 200
